30U VACBUILT
Key Features:
- (1) 30-gal (113.56-L) horizontal waste oil tank
- (1) Removable mounting plate for hose reel and controls
- (1) 25-ft reel
- No compressor
Description
The 30-gallon (113.56-L) VacBuilt waste oil tank is a great way to get started with onsite oil changes. It provides flexibility for preventive maintenance that doesn’t require a new bulk oil tank. The convenient package with hose reel and controls uses Sage Oil Vac’s no-pump vacuum technology to vacuum hot motor oil from equipment at up to eight gallons per minute.
This VacBuilt waste oil tank includes a 3/4-inch by 25-foot (1.905-cm x 7.6-m) hose on a spring retractable reel, a pressure gauge, a ball valve with a pressure relief setting, a ball valve with a vacuum setting and a removable mounting plate.
Specifications
POWER
- Additional air source required
- Vacuum generator for vacuum assist
- Push-on fitting at air inlet
HOSES AND REELS
- (1) 3/4-in by 25-ft (1.905-cm x 7.6-m) hose
- Spring retractable reel
SAGE OIL VAC ATTRIBUTES
- Patented vacuum process to remove used oil
- Enclosed system protects the operator and the environment
- No-pump system to reduce maintenance
- Versatile setup that can be used in shop or mounted in a truck
CONTROLS AND MOUNTING
- Removable mounting plate for mounting a hose reel and controls to the top of the tank or remotely
- Control panel includes a pressure gauge, a ball valve with a pressure relief setting and a ball valve with a vacuum setting
DIMENSIONS AND WEIGHTS
- Length: 38-3/4 in (98.4 cm)
- Width of tank: 16 in (40.6 cm)
- Height with hose reel mounted: 51-3/4 in (131.5 cm)
- Height without hose reel and removable control panel mounted: 20-7/16 in (52.0 cm)
- Shipping weight: 175 pounds (80 kg)
- Full tank weight: 397 pounds (180 kg)
Awards
- VacBuilt systems were named one of Construction Equipment’s Top 100 New Products of 2024. This prestigious recognition highlights products that demonstrate major advancements in technology, offer significant improvements, or introduce innovative solutions to the industry.
